plz help..
I took my car today from the shop.. I placed an OME suspension ARb lsd front and back, 4.88 gears. my car is 3.8 automatic 2door.
The problem is that when I go to the highway and I reach 55-60mph the whole cars starts to vibrate so much that I cant drive… (I have to slow down and then it stops..) it moves right and left all the time like my suspension goes right and left really fast. also the sterring whell goes right and left very very fast… if you see the car outside I think it is all shaking… At first I thought it was something wrong with my wheels.. and from that time, any time I reach 55-60mph it does it again.. every single time… I am sure it is going to break..
I cant even go straight... !!! lool it is funny
I have the stock 32tires. without spacers.. yet
Do you have anything in mind??
I will try to drive it again slowly and take it back to the shop i installed all the things.. The problem is that i dont know if it is from the gears from the arb diffs or from the suspension...
any ideas ?
Thank you for your help,
Nick
The problem is that when I go to the highway and I reach 55-60mph the whole cars starts to vibrate so much that I cant drive… (I have to slow down and then it stops..) it moves right and left all the time like my suspension goes right and left really fast. also the sterring whell goes right and left very very fast… if you see the car outside I think it is all shaking… At first I thought it was something wrong with my wheels.. and from that time, any time I reach 55-60mph it does it again.. every single time… I am sure it is going to break..
I cant even go straight... !!! lool it is funny
I have the stock 32tires. without spacers.. yet
Do you have anything in mind??
I will try to drive it again slowly and take it back to the shop i installed all the things.. The problem is that i dont know if it is from the gears from the arb diffs or from the suspension...
any ideas ?
Thank you for your help,
Nick
#3
JK Freak
Join Date: Oct 2008
Location: Colorado Springs, CO
Posts: 896
Likes: 0
Received 0 Likes
on
0 Posts
I took my car today from the shop.. I placed an OME suspension ARb lsd front and back, 4.88 gears. my car is 3.8 automatic 2door.
The problem is that when I go to the highway and I reach 55-60mph the whole cars starts to vibrate so much that I cant drive… (I have to slow down and then it stops..) it moves right and left all the time like my suspension goes right and left really fast. also the sterring whell goes right and left very very fast… if you see the car outside I think it is all shaking… At first I thought it was something wrong with my wheels.. and from that time, any time I reach 55-60mph it does it again.. every single time… I am sure it is going to break..
I cant even go straight... !!! lool it is funny
I have the stock 32tires. without spacers.. yet
Do you have anything in mind??
I will try to drive it again slowly and take it back to the shop i installed all the things.. The problem is that i dont know if it is from the gears from the arb diffs or from the suspension...
any ideas ?
Thank you for your help,
Nick
The problem is that when I go to the highway and I reach 55-60mph the whole cars starts to vibrate so much that I cant drive… (I have to slow down and then it stops..) it moves right and left all the time like my suspension goes right and left really fast. also the sterring whell goes right and left very very fast… if you see the car outside I think it is all shaking… At first I thought it was something wrong with my wheels.. and from that time, any time I reach 55-60mph it does it again.. every single time… I am sure it is going to break..
I cant even go straight... !!! lool it is funny
I have the stock 32tires. without spacers.. yet
Do you have anything in mind??
I will try to drive it again slowly and take it back to the shop i installed all the things.. The problem is that i dont know if it is from the gears from the arb diffs or from the suspension...
any ideas ?
Thank you for your help,
Nick
It's not your gear or diffs. The first thing I thought was the tires need balanced, but if this just started happening after the lift was installed, it's probably not the tires...
How much lift is the kit? Did you install it yourself? Did you replace your trackbar with an aftermarket one or relocate it?
Last edited by stlfan06; 11-10-2009 at 08:01 AM.
#4
JK-Forum Founder
Join Date: Jul 2006
Location: Laguna Niguel, CA
Posts: 36,534
Likes: 0
Received 16 Likes
on
15 Posts
speed related shimmy is typically a wheel balancing problem. however, if it's more of a violent shaking and to the point where you really cannot drive until you come to a stop, your shop probably didn't install your track bar correctly and/or tighten the bolts to the appropriate torque setting.
#5
JK Newbie
Thread Starter
Join Date: Feb 2008
Location: Athens Greece
Posts: 26
Likes: 0
Received 0 Likes
on
0 Posts
tank you for the quick reply.. the car has the Medium Ome front and hard back (I still havent placed a rear bumper) and it is too tall back... I took the packege from Northbridge and I installed brakelines and sway bar links front and back....
Last edited by pansil; 11-10-2009 at 08:01 AM.
#6
JK Super Freak
Join Date: Jun 2007
Location: Dayton, WA
Posts: 1,115
Likes: 0
Received 0 Likes
on
0 Posts
#7
JK Newbie
Thread Starter
Join Date: Feb 2008
Location: Athens Greece
Posts: 26
Likes: 0
Received 0 Likes
on
0 Posts
they also told me that for some reason they didnt manage to place the sway bar links in front because they didnt fit?! and they placed only back sway bars and in front they left the stock.. ...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
Trending Topics
#8
JK Freak
Join Date: Oct 2008
Location: Colorado Springs, CO
Posts: 896
Likes: 0
Received 0 Likes
on
0 Posts
they also told me that for some reason they didnt manage to place the sway bar links in front because they didnt fit?! and they placed only back sway bars and in front they left the stock.. ...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
Did you just add the LSD to the front? The rear should come with it from the factory...
#9
they also told me that for some reason they didnt manage to place the sway bar links in front because they didnt fit?! and they placed only back sway bars and in front they left the stock.. ...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
#10
JK Jedi Master
Join Date: Jan 2008
Location: Austin <--> Colorado Springs
Posts: 11,463
Likes: 0
Received 162 Likes
on
154 Posts
they also told me that for some reason they didnt manage to place the sway bar links in front because they didnt fit?! and they placed only back sway bars and in front they left the stock.. ...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
So the good think is that you all believe it is a suspension problem and not from the 4.88 or the lsds...
As the others have said, it is likely a trackbar issue. Have them tighten up the bolts on the front trackbar to 125 ft/lbs, with the JK on the ground. (If the bolts were tightened while on a lift with the suspension drooping, have them loosen the bolts and re-torque while on the ground)
Last edited by nthinuf; 11-10-2009 at 09:07 AM.
