Install Winch AFTER Lod Mid Width Front Bumper?
11-18-2009, 07:22 PM
#1
JK Enthusiast
Thread Starter
Join Date: Sep 2007
Location: Conifer, CO
Posts: 171
Likes: 0
Received 0 Likes
on
0 Posts
Install Winch AFTER Lod Mid Width Front Bumper?
Has anybody installed a winch on the LOD mid width front bumper after installing the bumper on the jeep?
The project JK site tells you to install the winch, then lift up the bumper and install it on the jeep. The problem is, I took off my stock bumper before I read this. I ordered my winch, but its on 2 month back order. So, I either have to install the LOD bumper and then take it off again later, or drive around with no bumper (not sure if that's even legal). I'd prefer to not do any of this twice...
The project JK site tells you to install the winch, then lift up the bumper and install it on the jeep. The problem is, I took off my stock bumper before I read this. I ordered my winch, but its on 2 month back order. So, I either have to install the LOD bumper and then take it off again later, or drive around with no bumper (not sure if that's even legal). I'd prefer to not do any of this twice...
11-18-2009, 08:52 PM
#4
JK Newbie
Join Date: Jul 2009
Location: Anaheim Hills, CA
Posts: 81
Likes: 0
Received 0 Likes
on
0 Posts
I think it might depend on the hoop style (or lack of a hoop) vs. the height of the winch.
I don't have a hoop on mine, and I have a Power Plant (tall winch). I have had it off and on a couple of times, and it's a piece of cake mounting it after the bumper is installed. That might not be the case if I had a low hoop.
-Randy
I don't have a hoop on mine, and I have a Power Plant (tall winch). I have had it off and on a couple of times, and it's a piece of cake mounting it after the bumper is installed. That might not be the case if I had a low hoop.
-Randy
11-19-2009, 02:59 AM
#5
JK Enthusiast
Join Date: Jul 2009
Location: Arnold, Missouri
Posts: 108
Likes: 0
Received 0 Likes
on
0 Posts
All this talk about cake and pie is making me hungry:-)
11-19-2009, 03:53 AM
#6
Sponsoring Manufacturer
Join Date: Jan 2007
Posts: 175
Likes: 0
Received 0 Likes
on
0 Posts
You want to Install the winch after you have the bumper on the Jeep. It makes it easier to install the bumper without the winch in the way. The winch will then Just bolt up from the bottom side.
11-19-2009, 04:29 AM
#7
JK Enthusiast
Join Date: May 2008
Location: Mount Juliet, TN
Posts: 429
Likes: 0
Received 0 Likes
on
0 Posts
Mount the winch after the bumper is on. Taking the grill off before putting the winch in will give you more room to work with.
https://www.jk-forum.com/forums/show...&highlight=lod
https://www.jk-forum.com/forums/show...&highlight=lod
Trending Topics
11-19-2009, 06:24 AM
#9
JK Enthusiast
Join Date: Mar 2009
Location: Chugiak, AK
Posts: 385
Likes: 0
Received 0 Likes
on
0 Posts
I did the LOD middy and put my XD9000I in afterward and also did NOT remove the grille. I just put a towel over the grill when dropping it in, just for protection.
What I didn't do was take it back out after finding out that the fairlead didn't line up perfectly with the winch. I took a 'wait and see' approach and now wished that I had drilled new mounting holes for the winch because it doesn't spool well and is damaging the cable a little as it rolls over on the end that is not covered well by the fairlead.
What I didn't do was take it back out after finding out that the fairlead didn't line up perfectly with the winch. I took a 'wait and see' approach and now wished that I had drilled new mounting holes for the winch because it doesn't spool well and is damaging the cable a little as it rolls over on the end that is not covered well by the fairlead.
11-19-2009, 07:07 AM
#10
JK Enthusiast
Join Date: Jul 2009
Location: Arnold, Missouri
Posts: 108
Likes: 0
Received 0 Likes
on
0 Posts
I did the LOD middy and put my XD9000I in afterward and also did NOT remove the grille. I just put a towel over the grill when dropping it in, just for protection.
What I didn't do was take it back out after finding out that the fairlead didn't line up perfectly with the winch. I took a 'wait and see' approach and now wished that I had drilled new mounting holes for the winch because it doesn't spool well and is damaging the cable a little as it rolls over on the end that is not covered well by the fairlead.
What I didn't do was take it back out after finding out that the fairlead didn't line up perfectly with the winch. I took a 'wait and see' approach and now wished that I had drilled new mounting holes for the winch because it doesn't spool well and is damaging the cable a little as it rolls over on the end that is not covered well by the fairlead.
Any comments about this from LOD?
